USD$182.53
Product Description: Mfg p/n: LKT-20-480-DD60, Capacitor, 3Phase, 20Kvar, 480V, Maximum Voltage(Continuous): 528V, 3x 76.7µF, 60Hz
Available on backorder
The unique design of Frako’s DD60 Capacitor takes into consideration reactor voltage boosting and harmonics on the electrical system! The DD60 Capacitor is versatile and effective in Power Factor Correction, De-tuned Power Factor Correction, and Harmonic Filters. FRAKO 3 Phase Capacitors are ideal for power factor improvement, tuned filters, and other power quality filter systems. Triple safety protection and high current capability are combined to deliver dependable performance under extreme conditions. Frako New DD60 Capacitors offer the UL and CSA market a powerful choice facing real-world issues such as harmonics and reactor voltage boosting.
| Shipping Weight | 5 lbs |
|---|---|
| Shipping Dimensions | 7 × 15 × 5 in |
| Mfg SKU | LKT-20-480-DD60 |
| Category | Power Factor Correction |
| Brand | Frako |
| Voltage | 480/528V |
| kVAR | 20kVAR |
| Phase | 3 |
| Rated Capacitance | 3x 76.7µF |
| Frequency | 60Hz |
| Agency Approvals | CE, CSA, cUL Recognized, UL Recognized |
| Product Dimensions: H x Dia (mm) | 313 MM x 85 MM |
| Product Weight (kg) | 1.9 KG |
| Product Dimensions: H x Dia (in) | 12.32 IN x 3.35 IN |
| Product Weight (lbs) | 4.19 LBS |
Product Description: Mfg p/n: LKT-15-480-DD60, Capacitor, 3Phase, 15Kvar, 480V, Maximum Voltage(Continuous): 528V, 3x 57.4µF, 60Hz
Product Description: Mfg p/n: LKT-12.5-480-DD60, Capacitor, 3Phase, 12.5Kvar, 480V, Maximum Voltage(Continuous): 528V, 3x 48.1µF, 60Hz
Product Description: Mfg p/n: LKT-7.5-240-DD60, Capacitor, 3Phase, 7.5Kvar, 240V, Maximum Voltage(Continuous): 264V, 3x 115.0µF, 60Hz
Product Description: Mfg p/n: LKT-11.7-480-DD60, Capacitor, 3Phase, 11.7Kvar, 480V, Maximum Voltage(Continuous): 528V, 3x 44.9µF, 60Hz
